PanTilt for Blackmagic design Micro Studio Camera

remote camera control via return SDI

The Micro Studio Camera is out of production, succeeded by Micro Studio Camera G2


This pan/tilt consists of a Visca serial interface mounted on a MP101 pan/tilthead, with a special cable that connects to the expansion port of a Blackmagic design Micro Studio Camera. The unit runs on 12V, and powers the camera via the expansion port. The camera outputs the Pan Tilt information that is embedded in the SDI return signal (along with shading and tally information) to the interface.
The pan/tilt and zoom can be controlled via Blackmagic design ATEM control panels, or via a serial Visca controller and PTZ translator.

The Micro Studio camera is often used for making overview shots, sometimes mounted on places that are difficult to reach. This pan/tilt solution enables you to remotely adjust your shot during broadcasting.
The MP101 head does not support presets.




Interface and MP101 pan/tilt head for Blackmagic design Micro Studio Camera.

MSRP: € 450,-


Interface only.

MSRP: € 250,-
